9T455,9T555,9T665
FMWORLD
| Color: | Please select |
|---|---|
| Quantity: | |
Key Features：
The large-diameter rotors not only allow for reduced speeds, minimizing damage to the forage, but also significantly enhance tedding capacity, enabling the turning of longer and heavier forage.
Each rotor is mounted on an independent floating frame, maintaining a consistent tedding angle.
Equipped with double hook tines, the tedder efficiently and gently turns the forage rather than stirring it, accelerating the drying process.
The double hook tines, due to their unique force distribution, boast exceptional durability.
The unique anti-wrap design effectively protects the rotors and bearings, improving operational efficiency.
| Model | 9T455 Tedder | 9T555 Tedder | 9T665 Tedder |
| Drive mode | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min | Tractor pulling/PTO output/540r/min |
| Suspension type | Rear | Rear | Rear |
| Installation type | Three point opening and closing | Three point opening and closing | Three point opening and closing |
| Minimum traction force (KW) | ≥25KW(≥35hp) | ≥25KW(≥35hp) | ≥35KW(≥48hp) |
| Working range(mm) | 4500 | 5500 | 6600 |
| Working speed (km/h) | 5-20 | 5-20 | 5-20 |
| Working dimensions (mm) | 2200*4500*1800 | 2200*5500*1800 | 2200*6600*1800 |
| Transportation dimensions (mm) | 2200*2650*2300 | 2200*2650*2300 | 2200*2950*2300 |
| Machine weight (KG) | 465 | 500 | 700 |
| Turntable diameter (mm) | 1480 | 1480 | 1480 |
| Number of turntables | 4 | 4 | 6 |
| Quantity of teeth and stems for each turntable | 6 | 6 | 6 |
| Tire specifications | 16*6.50-8 | 16*6.50-8 | 16*6.50-8 |
| Hydraulic folding | yes | yes | yes |
| center height adjustment | Adjustable | Adjustable | Adjustable |
