| Technical Parameter | |
| Model | W275W-10PLUS |
| Engine Model | YCF3065-T480 |
| Engine Power | 48KW/2200rpm |
| Maximum torque(N.M)/Rotational speed (r/min) | 260NM/1600rpm |
| Main pump form | Axial piston pump |
| Maximum flow rate of the main pump | 154L/min |
| Fuel tank capacity | 175 |
| Hydraulic oil tank capacity | 120 |
| Travel speed | 33 |
| Swing speed | 12 |
| Climbing ability | 35° |
| Bucket capacity | 0.3 |
| Working Range | |
| Specifications | 3400+1800 |
| Maximum digging height | 7020mm |
| Maximum unloading height | 5020mm |
| Maximum digging depth | 3550mm |
| Maximum vertical arm digging depth | 3040mm |
| Maximum digging distance | 6480mm |
| Minimum radius of turn | 2120mm |
| Maximum height at minimum turning radius | 5270mm |
| Maximum surface excavation area | 6480mm |
| Dimension | |
| Length | 6180mm |
| Width | 2220mm |
| Height (during transportation) | 2890mm |
| Height (top of cab) | 2796mm |
| Wheel pitch | 1670mm |
| Wheel base | 2380mm |
| Minimum ground clearance | 280mm |
| Radius of tail rotation | 1940mm |
